SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
Packing Method:
TR
Peak Reflow Temperature (Cel):
260
Power:
NO
Programmable Power:
NO
Qualification Status:
Not Qualified
Seated Height-Max:
1.07 mm
Slew Rate-Nom:
55 V/us
Subcategory:
Operational Amplifier
Supply Current-Max:
13.5 mA
Supply Voltage Limit-Max:
3.6 V
Supply Voltage-Nom (Vsup):
3.3 V
Surface Mount:
YES
Technology:
CMOS
Temperature Grade:
INDUSTRIAL
Terminal Finish:
Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form:
GULL WING
Terminal Pitch:
0.65 mm
Terminal Position:
DUAL
Time@Peak Reflow Temperature-Max (s):
30
Unity Gain BW-Nom:
100000
Voltage Gain-Min:
1000
Wideband:
YES
Width:
3 mm
THS4120IDGNR Frequently Asked Questions (FAQs)
Texas Instruments provides a recommended PCB layout in the THS4120EVM evaluation module documentation, which includes guidelines for component placement, routing, and grounding to minimize noise and ensure optimal performance.
The selection of input and output termination resistors depends on the specific application and signal requirements. Texas Instruments provides guidelines for selecting termination resistors in the THS4120 datasheet and application notes, including considerations for signal amplitude, frequency, and impedance matching.
The THS4120IDGNR is rated for operation over a temperature range of -40°C to 125°C, but the device's performance and reliability may be affected at extreme temperatures. It's essential to consider the operating temperature range in the system design and ensure proper thermal management.
To ensure EMC with the THS4120IDGNR, follow proper PCB design and layout practices, such as using a solid ground plane, minimizing signal loop areas, and using shielding and filtering components as needed. Additionally, consider the device's electromagnetic radiation and susceptibility characteristics, as specified in the datasheet.
The THS4120IDGNR requires a specific power sequencing to ensure proper operation and prevent damage. The datasheet provides guidelines for power sequencing, including the recommended sequence and timing for powering up and down the device.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
THS4120IDGNR Overview
Use the download button to access the THS4120IDGNR schematic symbol, PCB footprint, and 3D model.
