TMP468AIRGTR - Texas Instruments

Description: ±0.75⁰C High-Accuracy Multi-channel Remote and Local Temperature Sensor

Download TMP468AIRGTR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
TMP468AIRGTR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
TMP468AIRGTR - Texas Instruments PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - RGT0016C_2
click to zoom
3D Models
TMP468AIRGTR - Texas Instruments - 3D model - Quad Flat No-Lead - RGT0016C_2
click to zoom

TMP468AIRGTR Details

  • Manufacturer Part Number:

    TMP468AIRGTR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Accuracy-Max (Cel):

    0.35 Cel

  • Body Breadth:

    3 mm

  • Body Height:

    1 mm

  • Body Length or Diameter:

    3 mm

  • Housing:

    PLASTIC

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Bits:

    13

  • Number of Terminals:

    16

  • Operating Current-Max:

    0.375 mA

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Interface Type:

    2-WIRE INTERFACE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape/Style:

    SQUARE

  • Sensors/Transducers Type:

    TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    1.7 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Termination Type:

    SOLDER

TMP468AIRGTR Frequently Asked Questions (FAQs)

  • The TMP468AIRGTR can operate from -40°C to 125°C, but the accuracy specifications are only guaranteed from -20°C to 100°C.
  • The TMP468AIRGTR does not require calibration. It is a digital temperature sensor that provides a calibrated digital output. However, you may need to perform a one-time initialization to set the device's address and other configuration settings.
  • The conversion time for the TMP468AIRGTR is typically around 30 ms, but this can vary depending on the sampling rate and other factors. Refer to the datasheet for more information.
  • Yes, the TMP468AIRGTR has built-in noise filtering and error correction mechanisms to ensure reliable operation in noisy environments. However, it's still important to follow proper PCB design and layout practices to minimize noise and interference.
  • The TMP468AIRGTR communicates over an I2C interface, which is a standard serial communication protocol. You can use a microcontroller with an I2C peripheral to communicate with the TMP468AIRGTR. Refer to the datasheet and application notes for more information on interface and protocol details.
