TPS259482LYWPR - Texas Instruments

TPS259482LYWPR Details

• Manufacturer Part Number:

  TPS259482LYWPR

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  eFUSE

• Input Voltage-Max:

  23 V

• Input Voltage-Min:

  3.5 V

• JESD-30 Code:

  R-XBGA-B12

• Length:

  2.451 mm

• Moisture Sensitivity Level:

  1

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  9 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BGA

• Package Equivalence Code:

  BGA12(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.376 mm

• Supply Voltage-Max (Vsup):

  23 V

• Supply Voltage-Min (Vsup):

  3.5 V

• Supply Voltage-Nom (Vsup):

  12 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Position:

  BOTTOM

• Threshold Voltage-Nom:

  +2.4V

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  1.738 mm
