Texas Instruments provides a recommended layout and placement guide in the TPS6521901RHBR datasheet (Section 10.2) and in the application note 'TPS6521901RHBR Layout and Placement Guidelines' (SLUUAC5). It's essential to follow these guidelines to ensure proper thermal performance, noise reduction, and overall system reliability.
The TPS6521901RHBR is a programmable power management IC, and the output voltage can be set using external resistors (R1 and R2) connected to the FB pin. Use the voltage calculation formula provided in the datasheet (Section 7.3.1) to determine the correct resistor values for your desired output voltage.
The TPS6521901RHBR has an absolute maximum input voltage rating of 6.5V. However, the recommended operating input voltage range is 3.5V to 5.5V. Exceeding the absolute maximum rating can damage the device.
To ensure stability and reliability, follow the recommended component selection and layout guidelines, use a sufficient input capacitor (CIN) and output capacitor (COUT), and provide a stable input voltage. Additionally, consider using a soft-start circuit to reduce inrush current and prevent voltage overshoots.
The TPS6521901RHBR has an operating junction temperature range of -40°C to 125°C. However, the device's performance and reliability may degrade at higher temperatures. Consider using thermal management techniques, such as heat sinks or thermal interfaces, to maintain a safe operating temperature.
