A good PCB layout for the TPS71733DRVT involves placing the input and output capacitors close to the device, using a solid ground plane, and keeping the input and output traces separate to minimize noise coupling. Additionally, it's recommended to use a low-ESR capacitor for the output capacitor to ensure stability.
When choosing an output capacitor for the TPS71733DRVT, consider the output voltage, output current, and ripple requirements. A general rule of thumb is to use a capacitor with a capacitance value of at least 10uF and a voltage rating of at least 1.5 times the output voltage. Additionally, consider the ESR (Equivalent Series Resistance) of the capacitor, as a low ESR is recommended for stability.
The TPS71733DRVT has an absolute maximum input voltage rating of 6V. Exceeding this voltage can cause damage to the device. It's recommended to operate the device within the recommended input voltage range of 2.7V to 5.5V for optimal performance and reliability.
To ensure stability and prevent oscillation, follow the recommended PCB layout guidelines, use a low-ESR output capacitor, and ensure that the input and output capacitors are properly sized. Additionally, avoid using a capacitor with a high ESL (Equivalent Series Inductance) as it can cause oscillation. If oscillation occurs, try adding a small resistor (e.g., 10Ω) in series with the output capacitor to dampen the oscillation.
The TPS71733DRVT is rated for operation up to 125°C. However, the device's performance and reliability may degrade at high temperatures. It's recommended to derate the device's output current and voltage according to the temperature derating curve provided in the datasheet. Additionally, ensure that the device is properly heatsinked to prevent overheating.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS71733DRVT Overview
Use the download button to access the TPS71733DRVT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS71,
or try a keyword search, such as Linear Regulator ICs
