Texas Instruments provides a recommended PCB layout in the TUSB1210BRHBT datasheet, which includes a 4-layer PCB stack-up with a solid ground plane on the bottom layer, and a signal layer on the top layer. It's essential to follow this layout to ensure signal integrity and minimize electromagnetic interference (EMI).
To ensure signal integrity with the TUSB1210BRHBT, it's crucial to follow proper PCB design and layout guidelines, such as using a solid ground plane, minimizing trace lengths, and using differential pairs for USB signals. Additionally, using a common mode filter, such as the TUSB211, can help reduce electromagnetic interference (EMI) and improve signal quality.
The TUSB1210BRHBT supports USB 2.0 high-speed signals, which have a maximum cable length of 3 meters (10 feet) according to the USB 2.0 specification. However, the actual cable length may vary depending on the specific application and cable quality.
The TUSB1210BRHBT is a USB 2.0 repeater, and it's not designed to support USB 3.0 or USB 3.2 speeds. If you need to support higher speeds, you should consider using a USB 3.0 or USB 3.2 repeater, such as the TUSB926 or TUSB1046, respectively.
The TUSB1210BRHBT can be powered from a single 3.3V supply, and it's recommended to use a low-dropout regulator (LDO) to ensure a stable voltage supply. The device also has an internal voltage regulator, which can be used to generate the required 1.8V core voltage.
