UCC21530QDWKRQ1 - Texas Instruments

Description: Automotive, 4A, 6A, 5.7kVRMS, isolated dual-channel gate driver with EN and DT pins for IGBT/SiC , 3V ~ 18V , 14-SOIC , -40°C ~ 130°C (TJ)

Download UCC21530QDWKRQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
UCC21530QDWKRQ1 - Texas Instruments PCB footprint - Other - Other - DWK0014A_2026
click to zoom
3D Models
UCC21530QDWKRQ1 - Texas Instruments  - 3D model - Other - DWK0014A_2026
click to zoom

UCC21530QDWKRQ1 Details

  • Manufacturer Part Number:

    UCC21530QDWKRQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Japan, USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Date Of Intro:

    2018-12-08

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Built-in Protections:

    TRANSIENT; UNDER VOLTAGE

  • High Side Driver:

    YES

  • Input Characteristics:

    STANDARD

  • Interface IC Type:

    HALF BRIDGE BASED IGBT/MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e4

  • Length:

    10.3 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    STANDARD

  • Output Current Flow Direction:

    SOURCE AND SINK

  • Output Current-Max:

    6 A

  • Output Peak Current Limit-Nom:

    4 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP14/16,.4

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    2.65 mm

  • Supply Current-Max:

    3.5 mA

  • Supply Voltage-Max:

    18 V

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    3.3 V

  • Supply Voltage1-Max:

    25 V

  • Supply Voltage1-Min:

    14.7 V

  • Supply Voltage1-Nom:

    15 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Turn-off Time:

    0.03 µs

  • Turn-on Time:

    0.03 µs

  • Width:

    7.5 mm

UCC21530QDWKRQ1 Frequently Asked Questions (FAQs)

  • A good PCB layout for the UCC21530QDWKRQ1 involves keeping the high-frequency switching nodes (e.g., SW and VIN) away from sensitive analog nodes, using a solid ground plane, and minimizing the length of the power traces. TI provides a recommended PCB layout in the datasheet and application notes.
  • To ensure the UCC21530QDWKRQ1 operates within its SOA, monitor the device's junction temperature (TJ), input voltage (VIN), and output current (IOUT). Ensure TJ stays below 150°C, VIN is within the recommended range (4.5V to 18V), and IOUT does not exceed the maximum rating (3A).
  • When selecting L and COUT, consider the desired output voltage ripple, inductor core loss, and capacitor ESR. Choose an inductor with a high saturation current rating and low DCR. Select a capacitor with a high capacitance value, low ESR, and a voltage rating that exceeds the output voltage.
  • Implement OCP and SCP by monitoring the output current (IOUT) and voltage (VOUT). Use a current sense resistor (RSENSE) to detect overcurrent conditions. For SCP, monitor VOUT and IOUT to detect short-circuit conditions. Use the UCC21530QDWKRQ1's built-in OCP and SCP features or implement external protection circuits.
  • To manage thermal performance, ensure good airflow around the device, use a heat sink if necessary, and avoid blocking airflow to the device. Monitor the junction temperature (TJ) and ensure it stays below 150°C. Use thermal interface materials (TIMs) to improve heat transfer between the device and heat sink.
