Texas Instruments recommends a 4-layer PCB with a solid ground plane, and to keep the input and output traces as short as possible. Additionally, it's recommended to use a common mode choke or a ferrite bead to filter out high-frequency noise.
The LT1004IPW-1-2 is stable with a wide range of output capacitors, but it's recommended to use a capacitor with an ESR (Equivalent Series Resistance) of less than 1 ohm. Additionally, the output capacitor should be placed as close as possible to the regulator's output pin.
The maximum input voltage that can be applied to the LT1004IPW-1-2 is 15V, but it's recommended to keep the input voltage below 12V for optimal performance and to prevent overheating.
The LT1004IPW-1-2 has built-in overcurrent protection, but it's recommended to add an external fuse or a current-limiting resistor to protect the regulator from excessive current. Additionally, it's recommended to use a short-circuit protection device, such as a polyfuse, to protect the regulator from short-circuit conditions.
The LT1004IPW-1-2 has a thermal derating of 30°C/W, which means that the regulator's output current should be derated by 30°C/W above 25°C. For example, if the ambient temperature is 50°C, the output current should be derated by 50%.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
LT1004IPW-1-2 Overview
Use the download button to access the LT1004IPW-1-2 schematic symbol, PCB footprint, and 3D model.
